Our Products
Battery Chargers
High efficiency, compact battery chargers employing LLC resonant/Phase shift modulation.
- 2kW, 12/24/48/ for Lithium Ion and Lead Acid Batteries
- 3kW 48V for Lithium Ion and Lead Acid Batteries
Active Front End (AFE) Converter
Active Front-End Converter (AFC):Active Front-end Converter is aSiC/Gan MOSFET OR IGBT based high frequency AC to DC converter. It keeps supply side power factor to unity and supply current sinusoidal. Our AFC is also capable of feeding back the excessive power from DC link capacitor to grid side and so it is also popularly known as Regenerative Unit.
- Full digital control of boost/bridgeless PFC power converter
- 95 VAC to 265 VAC Single phase input voltage range
- 400 VDC bus output operating upto6 kW
- 3-Phase PFC
The 3-phase Vienna PFC design for Hybrid Electric Vehicle/Electric Vehicle (HEV/EV) charger, renewable energy and high-power switch mode power supply (SMPS) applications. This design is ideal for scaling up to higher power levels by interleaving multiple 25kW AFE’s.
Key Features:
- Designed for 25 kW and customized power level
- Next-generation Silicon Carbide IC (SiC) devices with high avalanche/repetitive Unclamped Inductive Switching (UIS)
- 3-phase 380/400V RMS input voltage, 50 Hz or 60 Hz
- More than 100 kHz switching frequency
- Output Voltage of 800V DC/ 900V Max
- Digital Signal Controller (DSC) for digital control
High Voltage DC, CW power supplies
Custom made various ranges like 4.2kV/7.2kV, 15kVupto15kWmagnetron power supply.
General Functions
- High voltage power generation
- Voltage control
The MW Power Supply is used for the generation and control of high voltage for magnetron
Pulse power supplies:
Solid state custom made High voltage pulse power supplies for Microwave devices, Plasma discharge etc.
BLDC Motor controller:
Fan/Exhaust controller for Electric cycle 200-1200 Watt
